2011年1月25日星期二

使用include重用UI組件

當我們的佈局有一些重複的UI元素, 我們可以使用<include>來節省我們的工作. 亦可以使用<include>, 在不同的活動(Activity)中使用相同的UI組件.

使用include重用UI組件

先創建重用的UI佈局文檔, sublayout.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:background="#505050"
>
<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="SubLayout"
/>
<Button
android:id="@+id/mybutton"
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text=" A Button "
/>
</LinearLayout>


在我們的主佈局文件包括<include>兩個重用的UI佈局.
main.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
>
<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="@string/hello"
/>
<include android:id="@+id/main1" layout="@layout/sublayout" />
<include android:id="@+id/main2" layout="@layout/sublayout" />
<Button
android:id="@+id/startanotheractivity"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text=" Start Another Activity "
/>
</LinearLayout>


在程序代碼中, 使用下面的方法來訪問個別元素:
View subLayout1 = (View)findViewById(R.id.main1);
Button myButton_main1 = (Button)subLayout1.findViewById(R.id.mybutton);

AndroidIncludeLayout.java
package com.AndroidIncludeLayout;

import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;
import android.widget.Toast;

public class AndroidIncludeLayout extends Activity {
/** Called when the activity is first created. */
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.main);

View subLayout1 = (View)findViewById(R.id.main1);
View subLayout2 = (View)findViewById(R.id.main2);
Button myButton_main1 = (Button)subLayout1.findViewById(R.id.mybutton);
Button myButton_main2 = (Button)subLayout2.findViewById(R.id.mybutton);
Button startAnotherActivity = (Button)findViewById(R.id.startanotheractivity);

startAnotherActivity.setOnClickListener(new Button.OnClickListener(){

@Override
public void onClick(View arg0) {
// TODO Auto-generated method stub
Intent intent = new Intent();
intent.setClass(AndroidIncludeLayout.this, AnotherActivity.class);
startActivity(intent);

}});

myButton_main1.setOnClickListener(new Button.OnClickListener(){

@Override
public void onClick(View arg0) {
// TODO Auto-generated method stub
Toast.makeText(AndroidIncludeLayout.this, "Button 1 Pressed", Toast.LENGTH_LONG).show();
}});

myButton_main2.setOnClickListener(new Button.OnClickListener(){

@Override
public void onClick(View arg0) {
// TODO Auto-generated method stub
Toast.makeText(AndroidIncludeLayout.this, "Button 2 Pressed", Toast.LENGTH_LONG).show();
}});
}
}


同樣, 在另一個佈局亦可以重複使用相同的元素.

使用include重用UI組件

anotherlayout.xml
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
>
<TextView
android:layout_width="fill_parent"
android:layout_height="wrap_content"
android:text="The Another Activity"
/>
<include android:id="@+id/main3" layout="@layout/sublayout" />

</LinearLayout>


AnotherActivity.java
package com.AndroidIncludeLayout;

import android.app.Activity;
import android.os.Bundle;
import android.view.View;
import android.widget.Button;
import android.widget.Toast;

public class AnotherActivity extends Activity {

@Override
protected void onCreate(Bundle savedInstanceState) {
// TODO Auto-generated method stub
super.onCreate(savedInstanceState);
setContentView(R.layout.anotherlayout);

View AnotherSubLayout = (View)findViewById(R.id.main3);
Button myButton_main3 = (Button)AnotherSubLayout.findViewById(R.id.mybutton);

myButton_main3.setOnClickListener(new Button.OnClickListener(){

@Override
public void onClick(View arg0) {
// TODO Auto-generated method stub
Toast.makeText(AnotherActivity.this, "Button 3 Pressed", Toast.LENGTH_LONG).show();
}});
}

}


記得, 如果你想運行此應用程序, 需要修改AndroidManifest.xml添加AnotherActivity活動(Activity).
